點擊圖片查看原圖二位二通常閉型電磁閥,斷電關閉,通電打開閥體材質為SS304不銹鋼(常規);
SS316不銹鋼(定制)
最大耐壓力為:40kgf/cm2
環境溫度:0℃～65℃(F級)、0℃～80℃(H級)
產品為系列化生產,體積小,流量大,適用范圍廣
按閥上所標流向箭頭,可任意安裝;為增強使用壽命,最好線圈向上,水平安裝
電壓:AC220V/230V/240V/110V/24V 50/60HZ DC24V/12V +10%到-10%允許波動
線圈可配德國原裝NASS線圈 常規備貨:AC220V/230V/240V 50/60HZ DC24V
密封件采用聚四氟乙烯材料(Teflon),以適用不同流體的開關控制
| 型號規格： |
|
接管
口徑 |
流量
通徑 mm |
CV值 |
線圈
配置 |
功率
|
線圈
等級 |
外形尺寸 長X寬X高 A x B x H |
重量
KG |
訂貨型號以下
表中電壓為 220CAC 50/60HZ |
|
|
VA
|
W
|
||||||||
|
AC220V
|
DC24V
|
||||||||
| 3/8'' | 8 | 4.5 | HTA1SF02T3D15 | ||||||
| 15 | 4.5 | D | 33 | 32 | F | 75x52x129 | 1.25 | HTA1DF02T1C15 | |
| 15 | 4.5 | W | 30 | 25 | H | 75x52x129 | 1.25 | HTA1WH02T1C15 | |
| 1/2'' | 15 | 4.5 | D | 33 | 32 | F | 75x52x129 | 1.2 | HTA1DF02T1D15 |
| 15 | 4.5 | W | 30 | 25 | H | 75x52x129 | 1.2 | HTA1WH02T1D15 | |
| 3/4'' | 20 | 9.0 | D | 33 | 32 | F | 85x60x141 | 1.5 | HTA1DF02T1E20 |
| 20 | 9.0 | W | 30 | 25 | H | 85x60x141 | 1.5 | HTA1WH02T1E20 | |
| 1'' | 25 | 13 | D | 33 | 32 | F | 100x70x148 | 1.9 | HTA1DF02T1G25 |
| 25 | 13 | W | 30 | 25 | H | 100x70x148 | 1.9 | HTA1WH02T1G25 | |
| 11/4'' | 35 | 26 | D | 33 | 32 | F | 120x90x168 | 3.6 | HTA1DF02T1H35 |
| 35 | 26 | W | 30 | 25 | H | 120x90x168 | 3.6 | HTA1WH02T1H35 | |
| 1/2'' | 35 | 26 | D | 33 | 32 | F | 120x90x168 | 3.5 | HTA1DF02T1J35 |
| 35 | 26 | W | 30 | 25 | H | 120x90x168 | 3.5 | HTA1WH02T1J35 | |
|
1'' |
25 | 13 | D | 33 | 32 | F | 134x110x185 | 3.4 | HTA1DF02T4F25 |
| 25 | 13 | W | 30 | 25 | H | 134x110x185 | 3.4 | HTA1WH02T4F25 | |
| 11/4'' 法蘭連接 |
35 | 26 | D | 33 | 32 | F | 160x135x200 | 6 | HTA1DF02T4F35 |
| 35 | 26 | W | 30 | 25 | H | 160x135x200 | 6 | HTA1WH02T4F35 | |
| 1 1/2'' 法蘭連接 |
40 | 26 | D | 33 | 32 | F | 160x145x205 | 6.5 | HTA1DF02T4F40 |
| 40- | 26 | W | 30 | 25 | H | 160x145x205 | 6.5 | HTA1WH02T4F40 | |
HTA1DF02T1C15,HTA1WH02T1C15,HTA1DF02T1D15,HTA1WH02T1D15,HTA1WH02T1E20,HTA1DF02T1G25,cclair,HTA1WH02T1G25,HTA1WH02T1J35,
HTA1DF02T4F25,HTA1WH02T4F25,HTA1DF02T4F35,HTA1WH02T4F35,
HTA1WH02T4F40,
